6-way Glass fuse block with Cover and negative bar for Vehicle Car Boat Marine Auto
price
USD3.50 - USD7.00 / pieces
SF50731
FOB
10 pieces
10000pieces / Month
FOB NINGBI
Quantity
- Place of Origin:CN;ZHE
- Type:glass fuse holders
- Brand Name:SUNFINE MARINE
- Model Number:SF50731
- Product Name:glass fuse holders,glass blocks
- Type:4/6/8 way
- Negatice bar:with/ without
- Label:70 pcs
- Voltage:32V dc max
- Application:glass fuse
- Packing:Standard Package
Product Description
6-way glass fuse holders with Cover and negative bar for Vehicle Car Boat Marine Auto
AB
C
fuse holder with cover
*Electrical
Main line:
Terminal rating: M5 threated studs
(100A 32V DC MAX.)
Wire size: #4-6 AWG
Single Line:
Terminal rating: M4 threated studs
(30A 32V DC MAX.)
Wire size: #12-16AWG
*Material
Base: PA66
Cap: PC
Terminal: Nickel plated copper
Screw: S.S
Label: PP x 70
*Fuse type
φ6.3 x 30mm φ6.3 x 32mm
For glass duse, fuse not included!!!
Detailed Images
